Customisable Bosch Smart System with Performance CX e-drive, Kiox 300 display and 750 (size S: 625) Wh battery

Robust metal mudguards, pannier rack, stand and super bright, smart LiteMove 110 Lux lighting system

Comfortable cockpit with C.I.S. stem with integrated cable routing, plus reliable Shimano Deore 11-speed shifting

Bosch CX e-drive & 750 (size S: 625) Wh battery

Fenders, pannier rack, stand and 110 Lux light

Comfortable C.I.S. cockpit & Shimano Deore 11-speed

• Brake
  • 180
• Pedal
  • MTB, with reflector
• Frame size
  • M,L,XL,S
  • 44,48,52,40
• Drive train
  • Chain
• Bike stand
  • rear stand, adjustable
• Max total weight
  • 150 kg
• Frame
  • 7005 hydroformed aluminium, 3D forging, 148x12 mm thru axle, USB-C port, post mount 180 mm
• Fork
  • SR Suntour XCR 34 LO Air, 15x110 mm
• Handlebar
  • Aluminium, 760 mm, flatbar, backsweep: 9°, 35,0 mm
• Saddle
  • Selle Royal Vivo
• Seat post
  • Aluminium, 31.6 mm
• Stem
  • FOCUS C.I.S. integrated, 60 mm, 30°, 35 mm, aluminium
• Brakes
  • Shimano MT410, 2-piston, hydraulic disc brake
• Crank set
  • FSA CK-320, aluminium
• Sprocket
  • Shimano Deore CS-M5100, 11-speed
• Transmission
  • front: 36, rear: 11-51
• Wheel rims
  • RODI TRYP25, 25-622
• Brake lever
  • Shimano MT410
• Item carrier
  • Racktime Snap-It carrier, 2-leg, 25 kg max. load
• Headlights
  • Litemove LED , 110 Lux
• Battery
  • Bosch Powertube, 750 Wh, removeable, lockable
  • 750 Wh,625 Wh
• Display
  • Bosch LED Remote + Kiox 300
• Motor
  • Bosch Performance CX Smart, 85 Nm, 250 W
• Color
  • Gold Brown
  • Toronto Grey
• Travel
  • 100 mm
• Hub
  • Shimano Alivio MT400, 15x110 mm
  • Shimano Alivio MT400, 12x148 mm
• Protective guard
  • Büchel, aluminium, 60 mm, powder-coated
• Grip
  • Herrmans Click
• Rear derailleur
  • Shimano Deore RD-M5100, 11-speed
• Tire
  • Schwalbe Smart Sam 2.25, 57-622
• Bottom bracket
  • Integrated in Drive Unit
• Shift/brake lever
  • Shimano MT410
  • Shimano Deore M5100, 11-speed
• Spoke
  • Zink, black
• Chain
  • Shimano CN-HG601, 11-speed
