Customisable Bosch Smart System with Performance CX e-drive, Kiox 300 display and 750 (size S: 625) Wh battery

SR Suntour Raidon LOR air suspension fork, 4-piston brakes and LiteMove 130 Lux lighting system with high beam for maximum safety in every situation

Comfortable cockpit with C.I.S. stem with integrated cable routing, plus precise Shimano XT 12-speed rear derailleur

Bosch CX e-drive & 750 (size S: 625) Wh battery

SR Suntour Raidon LOR fork, 4-piston brakes and 130 Lux light

Comfortable C.I.S. cockpit & Shimano XT 12-speed

SPECIFICATION

FRAME MATERIAL

Aluminium

FRAME

7005 hydroformed aluminium, 3D forging, 148x12 mm thru axle, USB-C port, post mount 180 mm

FORK

SR Suntour Raidon 34 LOR AIR, 110x15 mm

TRAVEL OF SUSPENSION FORK

100 mm

MOTOR

Bosch Performance CX Smart, 85 Nm, 250 W

BATTERY WATT-HOURS

750 Wh

BATTERY AMPERE HOURS

20,8 Ah

DISPLAY

Bosch LED Remote + Kiox 300

SHIFTER

Shimano Deore M6100, 12-speed

REAR DERAILLEUR

Shimano Deore XT M8100, 12-speed

SPROCKET

Shimano Deore CS-M6100, 12-speed

CHAIN

Shimano CN-LG50

CRANKSET

FSA CK-320, aluminium

TRANSMISSION OF DRIVE

front: 36, rear: 10-51

BOTTOM BRACKET

Integrated in Drive Unit

HANDLEBAR

Aluminium, 760 mm, flatbar, backsweep: 9°, 35,0 mm

STEM

FOCUS C.I.S. integrated, 60 mm, 30°, 35 mm, aluminium

HEADSET

ACROS ZS56/ZS66 (ICR), FOCUS C.I.S. Integrated

SADDLE

Selle Royal Vivo

SEATPOST

Aluminium, 31.6 mm

BRAKE CALIPER

Shimano MT420, 4-piston, hydraulic disc brake

BRAKE LEVER

Shimano BR-MT420

BRAKE

Disc

WHEELSET

Shimano WH-MT501, 24-622, 15x110 mm / 12x148 mm

TIRES

Schwalbe Smart Sam 2.25, 57-622

FENDER

Büchel, aluminium, 60 mm, powder-coated

HEADLIGHT

Litemove AE130, high-beam, 130 LUX

TAILLIGHT

Herrmans H-Trace Mini

GEARS

12

BIKE WEIGHT INCL. BATTERY IN KG.

26,6,*

SIZE

48,44,52
